All
Band Transceiver RECENT RS-918 27mhz
cb radio full-duplex walkie
talkie
Product Description
All Band Transceiver RECENT RS-918 27mhz cb
radio full-duplex walkie
talkie
|
Main
Features: |
|
|
Spectrum
Dynamic Waterfall
Display |
|
|
Receive Mode, Transceive
Mode, TUNE Mode, VFO Mode and SPLIT Mode |
|
|
DSP Digital Signal Processing Noise Reduction |
|
|
Automatic
Notch Filter Adopted |
|
|
Humanized
Interface Color Display |
|
|
RX Fine Tuning Function, MIC Gain Valume Adjustable |
|
|
VCC Power Supply Voltage Indication Table |
|
|
TX Signal Strength Display Table |
|
|
Multifunctional Instruments: SWR Standing Wave
Ratio Meter, AVD Audio Frequency Meter, |
|
|
|
|
|
General
Specifications |
|
|
Frequency
Range |
RX: 1.8-30MHz, TX: All HAM HF Bands |
|
Operating
Mode |
SSB(J3E), CW, AM(RX Only), FM, FREE-DV |
|
TX
Power |
5W(Standard, DC13.8V), 15W(Full, DC13.8V) |
|
Receiving
Sensitivity |
0.11-0.89uV(RFC50-20) |
|
Minimum
Frequency Step |
1Hz |
|
Operating
Voltage |
DC
9-15V |
|
Antenna
Impedance |
50ohm |
|
Frequency
Stability |
±1.5PPM @ Power on 5 Minutes
(Standard) ±0.5PPM if Optional TCXO Used |
|
Dimension(W*H*D) |
190mm*70mm*40mm |
|
Weight |
623g |
|
Operating
Current |
RX: <450mA; Around 65mA after Power Off
(Can be improved at 5mA) |
|
|
|
|
TX
Specifications |
|
|
Frequency
Band |
80-10m
All HF Ham
Band |
|
TX
Power |
Standard 5W (13.8VDC),15W
(FULL,13.8VDC) |
|
Modulation
Mode |
SSB Software Balanced Modulation, 10KHz FM, AM
Software Low Modulation (RX only) |
|
Spurious
Rejection |
>40dBC |
|
Carrier
Rejection |
>45dBC |
|
Selectivity |
SSB
2.3KHz (-6db) CW 500Hz (-6db) |
|
RX
Specifications |
|
|
IF
Frequency |
0 |
|
RX
Sensitivity |
>-115dBm |
|
Dynamic
Range |
>95dB |
|
RIT
Frequency Tuning
Range |
±1KHz |
|
Audio
Output |
8ohm,
0.5W |
Packaging & Shipping
All Band Transceiver RECENT RS-918 27mhz cb
radio full-duplex walkie
talkie
1 X V10 radio
1 X Battery
1 X Antenna
1X Belt Clip
1X User's Manual
1X
Charger
