Main
Features:
|
|
Spectrum
Dynamic Waterfall Display
|
|
Receive
Mode, Transceive Mode, TUNE Mode, VFO Mode and SPLIT Mode
|
|
DSP
Digital Signal Processing Noise Reduction
|
|
AutomaticNotch
Filter Adopted
|
|
Humanized
Interface Color Display
|
|
RX Fine
Tuning Function, MIC Gain Valume Adjustable
|
|
VCC
Power Supply Voltage Indication Table
|
|
TX
Signal Strength Display Table
|
|
Multifunctional
Instruments: SWR Standing Wave Ratio Meter, AVD Audio Frequency Meter,
ALC Signal Modulation Meter
|
|
|
General
Specifications
|
|
Frequency
Range
|
RX:
1.8-30MHz, TX: All HAM HF Bands
|
|
Operating
Mode
|
SSB(J3E),
CW, AM(RX Only), FM, FREE-DV
|
|
TX Power
|
5W(Standard,
DC13.8V), 15W(Full, DC13.8V)
|
|
ReceivingSensitivity
|
0.11-0.89uV(RFC50-20)
|
|
Minimum
FrequencyStep
|
1Hz
|
|
Operating
Voltage
|
DC 9-15V
|
|
AntennaImpedance
|
50ohm
|
|
FrequencyStability
|
±1.5PPM
@ Power on 5 Minutes (Standard) ±0.5PPM if Optional TCXO
Used
|
|
Dimension(W*H*D)
|
190mm*70mm*40mm
|
|
Weight
|
623g
|
|
Operating
Current
|
RX:
<450mA; Around 65mA after Power Off (Can be improved at 5mA)
TX: Max. 3A(FULL Power),1.5A(5W Power)
|
|
|
TX
Specifications
|
|
Frequency
Band
|
80-10m
All HF Ham Band
|
|
TX Power
|
Standard
5W (13.8VDC),15W (FULL,13.8VDC)
|
|
Modulation
Mode
|
SSB
Software Balanced Modulation, 10KHz FM, AM Software Low Modulation (RX
only)
|
|
SpuriousRejection
|
>40dBC
|
|
Carrier
Rejection
|
>45dBC
|
|
Selectivity
|
SSB
2.3KHz (-6db) CW 500Hz (-6db)
|
|
RX
Specifications
|
|
IF
Frequency
|
0
|
|
RX
Sensitivity
|
>-115dBm
|
|
Dynamic
Range
|
>95dB
|
|
RIT
Frequency Tuning Range
|
±1KHz
|
|
Audio
Output
|
8ohm,
0.5W
|
